Shacman 8x4 Crane Truck
The SHACMAN 8X4 Crane Truck is a powerful and versatile heavy-duty vehicle designed for construction, transportation, and lifting tasks. Powered by a Weichai WP12.400E32 engine with 400 horsepower, this 8x4 crane truck offers exceptional performance and fuel efficiency, all while meeting Euro V emission standards for a lower environmental impact.
Product Introduction
The SHACMAN 8X4 Crane Truck is a powerful and versatile heavy-duty vehicle designed for construction, transportation, and lifting tasks.
Technical Parameters
| Specification | Details |
|---|---|
| Model | SHACMAN 8X4 Crane Truck |
| Drive Type | 8×4 |
| Engine | Weichai WP12.400E32, 400 HP, 11.596 L, Turbocharged Diesel, Euro V Emission Standard |
| Transmission | 12-speed manual transmission for better power and fuel efficiency |
| Front Axle | Dual 7.5-ton front axles for stability and durability |
| Rear Axle | Dual 16-ton rear axles with 5.73 gear ratio |
| Suspension System | Multi-leaf spring suspension with shock absorbers for improved ride comfort |
| Braking System | Drum brakes with ABS (Anti-lock Braking System) and auxiliary engine brake |
| Crane Model | 8-ton or 10-ton capacity crane with advanced hydraulic lifting mechanism |
| Crane Reach | Maximum lifting height of 25 meters with reach up to 18 meters |
| Cabin | Spacious cabin with air-suspended driver's seat, climate control, and ergonomic design |
| Seats | Adjustable air-suspended seat for optimal comfort |
| Safety Features | ABS, Electronic Stability Control (ESC), Hill Start Assist, Crane overload protection system |
| Fuel Tank Capacity | 400L |
| Gross Vehicle Weight | 46,000 kg |
| Dimensions (L × W × H) | 12,200 mm × 2,550 mm × 3,950 mm |
| Wheelbase | 1,850 + 4,300 + 1,400 mm |
Key Features
· Weichai WP12.400E32 diesel engine with a 400 HP output and Euro V emission compliance.
· 8x4 axle configuration with dual front axles and dual rear axles layout.
· Reinforced ladder-type chassis frame structure for heavy-duty truck mounting applications.
· Hydraulic crane system with a 360° full-rotation slewing structure.
· Multi-section hydraulic boom structure for telescopic lifting configuration.
· Hydraulic control system integrated for crane operation.
· Left-hand / right-hand drive configuration options for international markets.
· Multi-speed manual transmission gearbox system.
· Heavy-duty suspension system with leaf spring configuration for multi-axle load distribution.
Why Trust Our SHACMAN 8X4 Crane Truck
· SHACMAN heavy-duty chassis applied in construction, mining, and logistics projects across Africa, Southeast Asia, the Middle East, and Latin America.
· Each crane unit is tested under full load before delivery.
· Truck and crane system configured for rough terrain, extreme temperature, and continuous heavy-duty operation conditions.
· Multi-language manuals, 24/7 remote technical support, and global spare parts supply with shipment to most regions.
FAQ
Q: What industries is this truck commonly supplied to?
A: Construction, infrastructure development, mining operations, and logistics material handling projects.
Q: What is the structure type of the crane system?
A: Hydraulic telescopic boom crane with 360° rotation structure.
Q: What drivetrain layout does the chassis use?
A: 8x4 heavy-duty axle configuration with dual front and rear axles.
Q: Is the steering configuration fixed?
A: It supports both left-hand and right-hand drive configurations depending on market requirements.
Q: What type of maintenance support is available internationally?
A: Remote technical support, documentation support, and spare parts supply network coverage.
